OLI CM Frequency & Voltage Converters in UAE
OLI CM Frequency & Voltage Converters
In professional concrete construction, consistent vibration performance is just as important as the vibrator itself. High-frequency internal and external concrete vibrators require a dedicated power supply capable of delivering stable voltage and frequency throughout the concrete placement process. Without the correct converter, even the highest-quality vibrator cannot operate at its intended performance.
The OLI CM Frequency & Voltage Converter Series has been engineered specifically to power OLI high-frequency concrete vibrators, providing a continuous 42 V, 200 Hz three-phase output from standard single-phase or three-phase electrical supplies. These electromechanical converters use a motor coupled with a permanent magnet generator to deliver stable power while maintaining operator safety through low-voltage operation.
At Liberty Enterprises, we supply genuine OLI CM Frequency & Voltage Converters in the UAE, helping contractors, precast manufacturers, ready-mix concrete plants, and infrastructure companies operate their high-frequency vibration systems with maximum reliability and efficiency.
Model Specifications
| Model | Frame Type | Outlets (No.) | Supply Electric Cable (m) | Weight (kg) | Input Voltage & Frequency | Input Current (A) | Input Power (kW) | Output Voltage & Frequency | Output Current (A) | Output Power (kVA) |
|---|---|---|---|---|---|---|---|---|---|---|
| CMM 11 | Handle | 1 | 3.5 | 17 | 230V, 1ph, 50Hz | 2.5 | 0.5 | 42V ±10%, 3ph, 200Hz | 11 | 0.8 |
| CMM 15 | Handle | 1 | 3.5 | 25 | 230V, 1ph, 50Hz | 6 | 1.1 | 42V ±10%, 3ph, 200Hz | 14 | 1.0 |
| CMM 25 | Frame | 2 | 3.5 | 34 | 230V, 1ph, 50Hz | 10 | 1.8 | 42V ±10%, 3ph, 200Hz | 25 | 1.8 |
| CMT 25 | Frame | 2 | 3.5 | 33 | 400V, 3ph, 50Hz | 5 | 2.8 | 42V ±10%, 3ph, 200Hz | 25 | 1.8 |
| CMT 35 | Wheeled | 3 | 5.0 | 41 | 400V, 3ph, 50Hz | 6 | 3.3 | 42V ±10%, 3ph, 200Hz | 36 | 2.6 |
| CMT 55 | Wheeled | 3 | 5.0 | 50 | 400V, 3ph, 50Hz | 9 | 5.0 | 42V ±10%, 3ph, 200Hz | 55 | 4.0 |
| CMT 85 | Wheeled | 4 | 5.0 | 56 | 400V, 3ph, 50Hz | 12 | 6.6 | 42V ±10%, 3ph, 200Hz | 85 | 6.2 |
What is a Frequency & Voltage Converter?
A frequency and voltage converter is an electromechanical device that transforms a standard electrical supply into the precise voltage and frequency required for high-frequency concrete vibrators.
Most high-frequency internal and external concrete vibrators are designed to operate at 42 V and 200 Hz, rather than directly from standard mains electricity. The CM Series converts either 230 V single-phase or 400 V three-phase input into the correct output needed for professional concrete vibration equipment.
This controlled power supply allows immersion vibrators and external vibrating motors to maintain a constant operating speed, ensuring consistent concrete consolidation throughout the entire pour.
Why Are Frequency & Voltage Converters Important?
Concrete consolidation depends on consistent vibration. Fluctuations in voltage or frequency can reduce vibrator performance, leading to incomplete compaction, trapped air, and inconsistent concrete quality.
The CM Series is designed to eliminate these issues by delivering a stable electrical output for continuous-duty operation. OLI’s design includes permanent magnet technology and an optimized cooling system that helps prevent overheating while supporting long operating cycles.
For contractors and precast manufacturers, this means:
- Stable vibration performance
- Consistent concrete density
- Reduced risk of honeycombing
- Reliable operation during long pours
- Improved productivity on site
Key Features of OLI CM Frequency & Voltage Converters
Stable 42V / 200Hz Output
The CM Series delivers the dedicated voltage and frequency required for professional concrete vibrators, ensuring consistent operating performance throughout the concrete placement process.
Continuous Duty Operation (S1)
Construction and precast applications often require equipment to operate for extended periods. The CM Series is designed for continuous S1 duty, providing dependable power throughout long working cycles without compromising performance.
Maintenance-Free Design
Permanent magnet technology eliminates many wear components found in conventional systems, resulting in a highly reliable converter that requires minimal routine maintenance.
Optimized Cooling System
A smooth cast aluminium body provides durability while making the unit easier to clean after use in demanding construction environments.
Applications Across UAE Industries
Benefits of Using OLI CM Frequency & Voltage Converters
Choosing the OLI CM Series provides several operational advantages:
- Stable power supply for high-frequency vibrators
- Continuous-duty operation
- Maintenance-free performance
- Efficient forced-air cooling
- Low-voltage operation for improved safety
- Durable aluminium construction
- Easy cleaning after site use
- Reliable operation in demanding construction environments
- Multiple model options for different project sizes
- Compatibility with a wide range of OLI vibration equipment
How to Select the Right CM Converter
Choosing the correct converter depends on:
Number of Vibrators
Different CM models can power one to four compatible high-frequency vibrators simultaneously.
Electrical Supply
Select a converter that matches your available site power supply, whether single-phase or three-phase.
Project Scale
Small building projects may require compact handle-type units, while large infrastructure and precast facilities benefit from higher-capacity frame or wheeled models.
Future Expansion
If additional vibrators may be required later, choosing a higher-capacity converter can provide greater operational flexibility.
Why Choose OLI?
OLI has established itself as a global leader in industrial vibration technology by developing complete concrete consolidation systems rather than standalone products.
The CM Series is engineered to work seamlessly with OLI high-frequency vibrators, providing dependable performance, long service life, and efficient operation in demanding construction and industrial environments.
Why Buy OLI CM Converters from Liberty Enterprises?
Liberty Enterprises supplies genuine OLI concrete vibration equipment across the UAE.
When you partner with Liberty Enterprises, you benefit from:
- Genuine OLI products
- Technical product selection assistance
- Fast delivery throughout the UAE
- Reliable after-sales support
- Solutions for contractors, precast manufacturers, and infrastructure companies
- Expertise in complete concrete consolidation systems
Whether you’re powering a single immersion vibrator on a building project or multiple vibrators in a precast production facility, our team can help you select the right CM converter for your application.
Related Categories
Complete your concrete vibration system with:
- OLI VH Internal Electric Concrete Vibrators
- OLI EWO High-Frequency Internal Vibrators
- OLI MVE-HF External Electric Concrete Vibrators
- OLI HFP Pneumatic External Vibrators
- Multiple Socket Panels (MSP-4)
- Control Panels
- Concrete Surface Preparation Equipment
Frequently Asked Questions
The OLI CM Series converts standard mains electricity into a 42 V, 200 Hz power supply required for operating compatible high-frequency internal and external concrete vibrators safely and efficiently.
Yes. Depending on the model, OLI CM converters can power between one and four compatible high-frequency vibrators simultaneously, provided the total load remains within the converter's rated capacity.
High-frequency vibrators are designed to operate at 42 V and 200 Hz, which standard mains electricity does not provide. A dedicated converter ensures stable performance, operator safety, and efficient concrete consolidation.
Yes. The CM Series is designed for continuous S1 duty, with forced ventilation and overload protection to support extended use in construction and precast production environments.
Liberty Enterprises supplies genuine OLI CM Frequency & Voltage Converters throughout the UAE, offering technical guidance, product selection support, and after-sales assistance for construction, infrastructure, and precast applications.
